The new radiometric thermal camera FLIR Vue Pro R gives both drone operators and certified thermographers the power to gather accurate, non-contact temperature measurements from an aerial perspective. Every still image the Vue Pro R saves contains accurate, calibrated temperature data embedded in every pixel, adding even more value to your sUAS operations and services than ever.

RADIOMETRY

The Vue Pro R is more than a thermal imager – it captures accurate, non-contact temperature measurements from an aerial perspective and saves images with calibrated temperature data embedded in every pixel.

MAVLINK INTEGRATION & CAMERA CONTROL

In addition to MAVLink compatibility for automated image capture and image geo-tagging, the same Accessory Port connection gives you access to two camera controls over PWM commands, so you can select color palettes, start and stop recording, or trigger the camera's e-zoom in-flight from your radio controller.

EASY TO CONFIGURE

Vue Pro comes with a built-in, low-power Bluetooth module, so you can easily configure your camera with our custom iOS or Android apps before you take off. Change color palettes, set your image optimization features, configure your PWM inputs, and start recording all without lugging a computer to the field.

FEATURES

• Radiometric imagery: Factory calibrated for accurate temperature measurements from an airborne perspective
• Easy installation: Accepts 5V DC input power and outputs analog video
• Easy set-up & configuration: Mobile app (iOS and Android) and built-in Bluetooth makes camera set-up a snap
• On-board recording: Records digital thermal video and stills to an on-board microSD card
• PWM control: Configure and control the camera in the air with up to four PWM inputs
• MAVLink interface: Trigger automated image capture and geo-tag images for mapping & survey missions
• Image optimization for drones
• Invertable image
• Color palettes
• Zoom

FLIR POWER AND HDMI VIDEO MODULE (Option)

Thanks to this tiny and easy-to-install module, you benefit from a HDMI digital video output 1280x720 @ 60Hz and from an integrated voltage regulator. It also offers protection against polarity inversion.

• FLIR Vue Pro R 640
  • Thermal imager: Uncooled VOx Microbolometer
  • Resolution: 640 x 512
  • Lens options: 9mm (69° x 56°) / 13mm (45° x 37°) / 19mm (32° x 26°)
  • Spectral band: 7.5 - 13.5 µm
  • Frame rates: 7.5 Hz (NTSC) / 8.3 Hz (PAL)
  • Measurement accuracy (-25°C to +135°C range): +/- 5°C or 5%
  • Measurement accuracy (-40°C to +550°C range): +/- 20°C or 20%
  • Size (lens included): 63 x 45 x 45 mm
  • Weight: 114 gr
  • Input voltage: DC 4.8 - 6.0V
  • Operational altitude: 40,000 ft
  • Radiometric temperature range: 0°C to +40°C
  • Operating temperature range: -20°C to +50°C

• FLIR Vue Pro R 336
  • Thermal imager: Uncooled VOx Microbolometer
  • Resolution: 336 x 256
  • Lens options: 6.8mm (45° x 35°) / 9mm (35° x 27°) / 13mm (25° x 19°)
  • Spectral band: 7.5 - 13.5 µm
  • Frame rates: 7.5 Hz (NTSC) / 8.3 Hz (PAL)
  • Measurement accuracy (-25°C to +135°C range): +/- 5°C or 5%
  • Measurement accuracy (-40°C to +550°C range): +/- 20°C or 20%
  • Size (lens included): 63 x 45 x 45 mm
  • Weight: 114 gr
  • Input voltage: DC 4.8 - 6.0V
  • Operational altitude: 40,000 ft
  • Radiometric temperature range: 0°C to +40°C
  • Operating temperature range: -20°C to +50°C

• FLIR Power & HDMI video module
  • ​Weight: 8 gr
  • Size: 43 x 34 x 10 mm
  • Fixe: on the Flir Vue Pro
  • Voltage: 5V (integrated regulator)
  • Power: 5V DC (640mA) - 28V DC (160mA)
  • Ouputs:
    • USB 10 pin: analog video, power and data transfer
    • HDMI: 1280x720 @ 60Hz
  • Protection against polarity inversion
  • LED indicator

• 1 x FLIR Vue Pro R
• 1 x Camera mount
• 1 x MicroSD card
• Bench cable
• Accessory cable

Be careful when choosing your lens as it is NOT interchangeable.

This product is available on a per order basis and involves a delivery delay of a couple days.
